2019 Cargo-Shade Cover Clips

ABS · Nylon1 FILECC-BY-NCInterior

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: 2019 Cargo-Shade Cover Clips
OEM: —
APPLICATION: Cherokee / Liberty KL

Loading 3D viewer...

CARGO ID · CJ-3D / 0907QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

2 PLATES

PLATE 01 / 02No caption recorded

Build sheet

MAN-0907

[01]2019-jeep-cherokee-trailhawk-cover-clips-v3.3mf2019-jeep-cherokee-trailhawk-cover-clips-v3.3mf.STL
[02]Bounding box135.202 × 40.293 × 25.241 mm
[03]Volume28,168.742 mm³

Field notes

BY CLINT G

Left- and right-side replacement end clips for the Mopar cargo-shade cover in a 2019 Cherokee KL Trailhawk. The source notes an 8.8 mm shaft diameter and recommends a tougher material than PLA.

View original source ↗
