Cut-Dash Storage Box

ABS · Nylon · PETGMULTI-PART2 FILESCC-BYDashboard

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Cut-Dash Storage Box
OEM: —
APPLICATION: CJ-7

Loading 3D viewer...

CARGO ID · CJ-3D / 0997QTY 2 · STLHANDLE · NO SUPPORTS

Field photographs

4 PLATES

PLATE 01 / 04No caption recorded

Build sheet

MAN-0997

[01]Jeep_Box_with_tabs.stlJeep_Box_with_tabs.stl.STL
[02]Jeep_Box_without_tabs-1.stlJeep_Box_without_tabs-1.stl.STL
[03]Bounding box195.000 × 101.520 × 63.600 mm
[04]Volume211,484.444 mm³

Field notes

BY PATRICK SHRIER (SCOUT1067)

Two-piece storage box for covering an oversized aftermarket-radio opening cut into a 1981 CJ-7 dashboard. Tabbed and plain halves glue together and convert the damaged opening into a useful cubby.
