Front Seat-Belt Anchor Cover

ABS · Nylon · PETG1 FILECC-BYInterior

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Front Seat-Belt Anchor Cover
OEM: —
APPLICATION: Grand Cherokee WK / WH

Loading 3D viewer...

CARGO ID · CJ-3D / 0953QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

6 PLATES

PLATE 01 / 06No caption recorded

Build sheet

MAN-0953

[01]zaglushka12.stlzaglushka12.stl.STL
[02]Bounding box132.151 × 96.065 × 20.415 mm
[03]Volume34,194.35 mm³

Field notes

BY ALEXEY MIROSHIN (MRMIROLEX)

Replacement outer cover for the front-passenger seat-belt anchor on a 2008 Grand Cherokee WK or WH. The source includes the factory part, printed geometry, and physical fit views.

View original source ↗
