Auxiliary-Battery Lead Insulator

TPU1 FILEGPLElectrical

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Auxiliary-Battery Lead Insulator
OEM: —
APPLICATION: Gladiator JT

Loading 3D viewer...

CARGO ID · CJ-3D / 0982QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

2 PLATES

PLATE 01 / 02No caption recorded

Build sheet

MAN-0982

[01]gladiatorbatteryterminalcover-body.stlgladiatorbatteryterminalcover-body.stl.STL
[02]Bounding box82.550 × 44.450 × 38.100 mm
[03]Volume25,216.419 mm³

Field notes

BY THEGREYWIZARD

Flexible insulating boot for the disconnected cable end left by a non-invasive Gladiator JT auxiliary-battery delete. The source documents the installed cover after towing use and recommends securing its neck with tape.
