Double-DIN Radio Dash Kit

ABS · Nylon · PETG1 FILECC-BYDashboard

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Double-DIN Radio Dash Kit
OEM: —
APPLICATION: Cherokee / Liberty KK / Liberty, Commander XK / XH, Grand Cherokee WK / WH, Wrangler JK

Loading 3D viewer...

CARGO ID · CJ-3D / 0948QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

3 PLATES

PLATE 01 / 03No caption recorded

Build sheet

MAN-0948

[01]Jeep_Chrysler_Dodge_Double_din_dash_kit.stlJeep_Chrysler_Dodge_Double_din_dash_kit.stl.STL
[02]Bounding box235.093 × 105.789 × 37.526 mm
[03]Volume60,752.525 mm³

Field notes

BY ANDRE PALOMO (CREATINGMARS)

Double-DIN radio mounting kit for 2008–2010 Grand Cherokee WK and WH dashboards. The creator leaves mounting holes undrilled for the chosen head unit and explicitly documents identical fitment in 2008–2010 Commander, 2008–2012 Liberty, and 2007–2017 Wrangler dashboards.

View original source ↗
