Illuminated License-Plate Bracket

ABS · Nylon · PETGMULTI-PART2 FILESCC-BYExterior

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Illuminated License-Plate Bracket
OEM: —
APPLICATION: CJ-5, CJ-7, CJ-8 Scrambler, Wrangler YJ

Loading 3D viewer...

CARGO ID · CJ-3D / 0715QTY 2 · STLHANDLE · NO SUPPORTS

Field photographs

2 PLATES

PLATE 01 / 02No caption recorded

Build sheet

MAN-0715

[01]Jeep_license_plate_bracket_v3.stlJeep_license_plate_bracket_v3.stl.STL
[02]lens_for_license_plate_light_v1.stllens_for_license_plate_light_v1.stl.STL
[03]Bounding box225.000 × 174.000 × 17.000 mm
[04]Volume95,176.546 mm³

Field notes

BY CHUCK BRYANT (3RDPIG)

License-plate bracket with a channel for an LED strip and a separate clear printable lens. The two-part design mounts in the stock late-CJ and YJ location.
