Roll-Up Tonneau-Cover Brackets

ABS · NylonMULTI-PART2 FILESCC-BY-NC-SABody

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Roll-Up Tonneau-Cover Brackets
OEM: —
APPLICATION: Gladiator JT

Loading 3D viewer...

CARGO ID · CJ-3D / 0980QTY 2 · STLHANDLE · NO SUPPORTS

Field photographs

2 PLATES

PLATE 01 / 02No caption recorded

Build sheet

MAN-0980

[01]tonneau-bracket-l-mk5.stltonneau-bracket-l-mk5.stl.STL
[02]tonneau-bracket-r-mk5.stltonneau-bracket-r-mk5.stl.STL
[03]Bounding box93.998 × 91.000 × 53.000 mm
[04]Volume140,728.284 mm³

Field notes

BY ECNO926

Left and right replacement brackets for the Mopar roll-up tonneau cover on 2020-and-newer Gladiator JT beds. Each bracket accepts two M5 threaded inserts; the creator reports that the pair fits and works.
