Three-Switch Dashboard Panel

ABS · Nylon · PETG1 FILECC-BY-NC-SADashboard

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Three-Switch Dashboard Panel
OEM: —
APPLICATION: Wrangler YJ

Loading 3D viewer...

CARGO ID · CJ-3D / 0724QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

2 PLATES

PLATE 01 / 02No caption recorded

Build sheet

MAN-0724

[01]YJ_Dash_switch_panel.stlYJ_Dash_switch_panel.stl.STL
[02]Bounding box108.000 × 101.481 × 22.250 mm
[03]Volume32,907.858 mm³

Field notes

BY JACOB MULCAHY (PSYCHOBILLYMAN)

Close replica of the factory dashboard switch plate with openings for three standard toggle switches. The creator printed and installed the panel in PETG.

View original source ↗
