Windshield Defrost-Vent Clip

ABS · Nylon · PETG1 FILECC-BYDashboard

DA FORM 2410 — COMPONENT RECORDFIG 3-14

Loading 3D viewer...

CARGO ID · CJ-3D / 0894QTY 1 · STLHANDLE · NO SUPPORTS

Field photographs

1 PLATE

PLATE 01 / 01No caption recorded

Build sheet

MAN-0894

[01]Jeep_Liberty_Dashboard_Vent_Clip.stlJeep_Liberty_Dashboard_Vent_Clip.stl.STL
[02]Bounding box35.000 × 29.800 × 28.000 mm
[03]Volume5,843.662 mm³

Field notes

BY JOE VECCHIONE (JVECCHIONE)

Replacement retaining clip for the windshield defrost vent in a Jeep Liberty KJ dashboard.
