Six-Switch Media-Center Panel

ABS · Nylon · PETGMULTI-PART2 FILESCC-BYDashboard

DA FORM 2410 — COMPONENT RECORDFIG 3-14

NOMENCLATURE: Six-Switch Media-Center Panel
OEM: —
APPLICATION: Gladiator JT, Wrangler JL

Loading 3D viewer...

CARGO ID · CJ-3D / 0986QTY 2 · STLHANDLE · NO SUPPORTS

Field photographs

2 PLATES

PLATE 01 / 02No caption recorded

Build sheet

MAN-0986

[01]jeep_gladiator_gl_dash_cover_buttons_right.stljeep_gladiator_gl_dash_cover_buttons_right.stl.STL
[02]jeep_gladiator_gl_dash_cover_buttons_right_back.stljeep_gladiator_gl_dash_cover_buttons_right_back.stl.STL
[03]Bounding box64.726 × 59.943 × 11.790 mm
[04]Volume21,955.952 mm³

Field notes

BY URCH

Two-piece six-switch panel that replaces the right-side media-center trim in Wrangler JL and Gladiator JT dashboards. The rear plate and switch retaining nuts clamp the assembly around the factory opening.
